Precision CNC Parts, Hydraulic Cylinders & Automation Components

Overland Engineering and Logistics manufactures and stocks precision components for OEM equipment builders across construction, agriculture, material handling, and industrial automation. This catalog lists parts available for direct order — hydraulic cylinders in telescopic, welded, and tie-rod configurations; CNC-machined and die-cast components; and electric automation hardware including brushless DC motors, servo drives, stepper motors, and industrial LiDAR sensors.

Every part is produced across our ISO-certified manufacturing hubs in Vietnam, Malaysia, and China, and buffered through our Missouri warehouse for just-in-time North American delivery. Filter by bore, stroke, mounting style, rated voltage, torque, or connector type using the panel on the left, or narrow by category to compare within a product family.

Not finding your specification? Most of what we ship is built to print. Send us a drawing and we will quote a custom run — request a quote or contact our engineering team.

Public Pricelist
Sort By: Featured
  • Hydraulic Cylinders
  • CNC Services
  • Casting Services
  • Motors
  • Radar
  • CLAMP FITTING
24mm Planetary Gearsbox Plus 24mm Brushless Motor
Voltage Range:3-24V
Speed Range:3,000-15,000rmp
Internal Drive/External Drive
Advantage :Low voltage / Low speed / High torque
Note: Specific parameters and dimensions can be customized and designed according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 12/24
Rated Rotate Speed(rmp) : 4500
Rated Current(A) : 0.33/0.18
Rated Torque(g.cm） : 250
Power(W) : 2.3
28mm Planetary Gearsbox Plus 28mm Brushless Motor
Voltage Range:3-24V
Speed Range:3,000-15,000rmp
Internal Drive/External Drive
Advantage :Low voltage / Low speed / High torque
Note: Specific parameters and dimensions can be customized and designed according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 12/24
Rated Rotate Speed(rmp) : 4200/4400
Rated Current(A) : 0.55/0.3
Rated Torque(g.cm） : 100
Power(W) : 4.3/4.5
Weight(g) : 200
36mm Planetary Gearsbox Plus 36mm Brushless Motor
Voltage Range:3-24V
Speed Range:3,000-15,000rmp
Internal Drive/External Drive
Advantage :Low voltage / Low speed / High torque
Note: Specific parameters and dimensions can be customized and designed according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 12/24
Rated Rotate Speed(rmp) : 5300/3400
Rated Current(A) : 1.4/0.42
Rated Torque(g.cm） : 200
Power(W) : 11/7
Weight(g) : 420
42mm Planetary Gearsbox Plus 42mm Brushless Motor
Voltage Range:3-24V
Speed Range:3,000-15,000rmp
Internal Drive/External Drive
Advantage :Low voltage / Low speed / High torque
Note: Specific parameters and dimensions can be customized and designed according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 12/24
Rated Rotate Speed(rmp) : 3400/3550
Rated Current(A) : 2.5/1.3
Rated Torque(g.cm） : 500
Power(W) : 17/18
Weight(g) : 650
60mm Planetary Gearsbox Plus 60mm Brushless Motor
Voltage Range:3-24V
Speed Range:3,000-15,000rmp
Internal Drive/External Drive
Advantage :Low voltage / Low speed / High torque
Note: Specific parameters and dimensions can be customized and designed according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 12/24
Rated Rotate Speed(rmp) : 3050
Rated Current(A) : 1.9/1
Rated Torque(g.cm） : 400
Power(W) : 12.5
Weight(g) : 2000
口40-50W , AC servo motor
Compact size (industry's shortest dimension)
High protection (IP65/67 protection rating)
Simple and elegant (bright color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 220
Rated Torque(N·m） : 0.16
Rated Rotate Speed(rmp) : 3000
Rated Current(A) : 0.39
Length (mm) : 84/56.7
Color : Sliver
Encoder : M17/E23
Brake : E/F
Power(W) : 50
Frame : 40
Connector Type : 1-AMP/4-Plug in
口40-100W, AC servo motor
Compact size (industry's shortest dimension)
High protection (IP65/67 protection rating)
Simple and elegant (bright color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 220
Rated Torque(N·m） : 0.32
Rated Current(A) : 0.92
Length (mm) : 95/67.5
Color : Sliver
Encoder : M17/E23
Brake : E/F
Connector Type : 1-AMP/4-Plug in
Rated Rotate Speed(rpm) : 3000
口60-200W,AC servo motor
Compact size (industry's shortest dimension)
High protection (IP65/67 protection rating)
Simple and elegant (bright color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 220
Rated Torque(N·m） : 0.64
Rated Current(A) : 1.5
Length (mm) : 101.1/71.8
Color : Sliver
Encoder : M17/E23
Brake : E/F
Connector Type : 1-AMP/4-Plug in
Rated Rotate Speed(rpm) : 3000
口60-400W,AC servo motor
Compact size (industry's shortest dimension)
High protection (IP65/67 protection rating)
Simple and elegant (bright color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 220
Rated Torque(N·m） : 1.27
Rated Current(A) : 2.1
Length (mm) : 119.5/90.1
Color : Sliver
Encoder : M17/E23
Brake : E/F
Connector Type : 1-AMP/4-Plug in
Rated Rotate Speed(rpm) : 3000
口60-600W,AC servo motor
Compact size (industry's shortest dimension)
High protection (IP65/67 protection rating)
Simple and elegant (bright color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 220
Rated Torque(N·m） : 1.91
Rated Current(A) : 3.7
Length (mm) : 139.5/110.1
Color : Sliver
Encoder : M17/E23
Brake : E/F
Connector Type : 1-AMP/4-Plug in
Rated Rotate Speed(rpm) : 3000
口80-750W,AC servo motor
Compact size (industry's shortest dimension)
High protection (IP65/67 protection rating)
Simple and elegant (bright color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 220
Rated Torque(N·m） : 2.39
Rated Current(A) : 4.1
Length (mm) : 126.7/95.7
Color : Sliver
Encoder : M17/E23
Brake : E/F
Connector Type : 1-AMP/4-Plug in
Rated Rotate Speed(rpm) : 3000
口80-1000W,AC servo motor
Compact size (industry's shortest dimension)
High protection (IP65/67 protection rating)
Simple and elegant (bright color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 220
Rated Torque(N·m） : 3.18
Rated Current(A) : 5.7
Length (mm) : 139.7/108.7
Color : Sliver
Encoder : M17/E23
Brake : E/F
Power(W) : 1000
Frame : 80
Connector Type : 1-AMP/4-Plug in
Rated Rotate Speed(rpm) : 3000
口40-50W ,DC servo motor
Small size (industry's ultra-short dimension)
High protection (IP65/67 protection level)
Simple and elegant (black lustrous color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 48
Rated Torque(N·m） : 0.16
Rated Current(A) : 3
Length (mm) : 84/56.7
Color : Black
Encoder : M17/E23
Brake : E/F
Power(W) : 50
Frame : 40
Connector Type : 3-Aircraft plug
Rated Rotate Speed(rpm) : 3000
口40-100W,DC servo motor
Small size (industry's ultra-short dimension)
High protection (IP65/67 protection level)
Simple and elegant (black lustrous color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 48
Rated Torque(N·m） : 0.32
Rated Current(A) : 5.7
Length (mm) : 95/67.7
Color : Black
Encoder : M17/E23
Brake : E/F
Power(W) : 100
Frame : 40
Connector Type : 3-Aircraft plug
Rated Rotate Speed(rpm) : 3000
口60-200W,DC servo motor
Small size (industry's ultra-short dimension)
High protection (IP65/67 protection level)
Simple and elegant (black lustrous color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 48
Rated Torque(N·m） : 3000
Rated Current(A) : 10
Length (mm) : 101.1/71.8
Color : Black
Encoder : M17/E23
Brake : E/F
Power(W) : 200
Frame : 60
Connector Type : 3-Aircraft plug
口60-400W ,DC servo motor
Small size (industry's ultra-short dimension)
High protection (IP65/67 protection level)
Simple and elegant (black lustrous color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 48
Rated Torque(N·m） : 1.27
Rated Current(A) : 19.9
Length (mm) : 117.9/88.6
Color : Black
Encoder : M17/E23
Brake : E/F
Power(W) : 400
Frame : 60
Connector Type : 3-Aircraft plug
Rated Rotate Speed(rpm) : 3000
Motor Module
Inquire
Inquire
Encoder : M17/E23
Power(W) : 50-1000
Frame : 40/60/80
Frameless Motors
Low temperature rise: Motor loss reduced by 20%
High density: Motor torque increased by 10%
Long-range battery life: Extended battery duration
Product Composition:
UVW Power Cable ,Stoop Loop ,Magnetic Steel, Stator Core, Potting Adhesive
Note: Hall Temperature Sensors and Outlet Forms are optional.
Inquire
Inquire
External Diameter : 50/70/85/115 mm
Voltage(V) : 24-380
temperature sensor : T/P/N/S
Hall sensor : H/X/N/S
HJ-Humanoid Joint Solution
Gear Ratio:51-161
Peak Torque(Nm):3.3-390
Rated torque(Nm): 1.8-36.3
Rated Speed(RPM): 4.6 - 180
Other load models can be customized in detail.
Inquire
Inquire
Brake : E/F
Voltage(V) : 24/48
Module outer diameter : 40-80
Length and load-bearing capacity : F/H/T
Diver : D
口60-600W,DC servo motor
Small size (industry's ultra-short dimension)
High protection (IP65/67 protection level)
Simple and elegant (black lustrous color & integrated structure)
Note: Other parameters such as voltage, torque and speed can be customized according to customer requirements.
Inquire
Inquire
Rated Voltage(V) : 48
Rated Torque(N·m） : 1.91
Rated Current(A) : 15
Length (mm) : 138.1/108.6
Color : Black
Encoder : M17/E23
Brake : E/F
Power(W) : 600
Frame : 60
Connector Type : 3-Aircraft plug
Rated Rotate Speed(rpm) : 3000
