Commercial / Parker Replacement S42DB-8-51 SAT Dump Hoist Hydraulic Cylinders

https://oelus.com/web/image/product.template/1030/image_1920?unique=f361a0e
Contact Us

This product has no valid combination.

Terms and Conditions

Technical Specifications

General
Fits ManufacturerCommercial/Parker
Weight155.00 lbs
Dimensions
Telescopic Stages2
Closed Length33.87 in
Open Extended Length84.870 in
Telescopic Stroke51 in
Largest Stage OD4.000 in
Mounting
Base End Mount TypeCross-Tube
Base Mount Width5.000 in
Base Pin Size2.000 in
Rod End Mount TypeDrilled Thru Rod
Rod Mount Width2.620 in
Rod Pin Size1.500 in
Ports
Retract Port / Plunger.50" NPT
