Binotto Replacement B3C 4.5-3-090-AV01 SAT Telescopic Hydraulic Cylinders
Technical Specifications
General
| Fits Manufacturer | Binotto |
|---|---|
| Weight | 250.00 lbs |
Dimensions
| Telescopic Stages | 3 |
|---|---|
| Closed Length | 41.25 in |
| Open Extended Length | 131.250 in |
Mounting
| Base End Mount Type | Trunnion |
|---|---|
| Rod End Mount Type | Trunnion |
Ports
| Extend Port / Plunger | -12 SAE ORB Out Base of Trunnion |
|---|
Trunnion
| Trunnion Closed | 5.250 in |
|---|---|
| Trunnion Open | 95.250 in |
| Trunnion Pin Diameter | 1.870 in |
| Trunnion Pin Length | 2.000 in |
| Trunnion Width | 9.750 in |
