Binotto Replacement 6.5-4-180-AV01 SAT Telescopic Hydraulic Cylinders
This product has no valid combination.
Technical Specifications
General
| Fits Manufacturer | Binotto |
|---|---|
| Weight | 562.00 lbs |
Dimensions
| Telescopic Stages | 4 |
|---|---|
| Closed Length | 56.063 in |
| Open Extended Length | 238.063 in |
| Telescopic Stroke | 182 in |
| Largest Stage OD | 6.000 in |
Mounting
| Base End Mount Type | Trunnion |
|---|---|
| Rod End Mount Type | Trunnion |
Ports
| Extend Port / Plunger | -16 SAE ORB Out Base Trunnion |
|---|
Trunnion
| Trunnion Closed | 6.850 in |
|---|---|
| Trunnion Open | 188.850 in |
| Trunnion Pin Diameter | 2.250 in |
| Trunnion Pin Length | 2.000 in |
| Trunnion Width | 11.938 in |
